Bricasti
M11 Series II R2R Digital to Analog Converter
$12,500.00 USDFeatures
Premium 20-bit ladder-type D/A conversion for natural, transparent sound reproduction
Advanced MDx digital processor with proprietary filter technology
Ultra-low jitter (8 psec @ 48kHz) using Direct Digital Synthesis (DDS) clocking
Multiple digital inputs including AES/EBU, SPDIF, Toslink, USB, and optional network player
Full DSD support up to DSD256 via USB (DSD64/128 via other inputs)
Selectable digital filters for personalized listening experience
Balanced (XLR) and unbalanced (RCA) analog outputs
Handcrafted in USA with precision-machined aluminum chassis
What's in the Box?
Warranty
The M11 R2R Series II is the concentration of the Ladder D/A technology found in the flagship Bricasti Design M21 without compromise. The M11 R2R Series II features the fit, finish and sonic qualities of the Series II analog design, chassis and MDx processor.
Elegant and refined
The M11 utilizes resistor ladder D/A technology coupled with the latest proprietary MDx digital platform, clocking algorithms and filter technology for exceptional performance without the use of SRC's so signals stay native and true. The digital section is coupled with a pristine analog path with the goal to deliver the truest possibly representation of tonality, precision and dimension.
Superb Analog
A high-performance linear power architecture allows for a clean signal with extremely low noise and expansive headroom. Featuring Point-to-point wiring and stillpoint isolation integrated directly into the chassis, you will experience new depth, detail and dimensionality in your music. Improved spacial cues and separation create a truly immersive experience.
Network Player
The optional Network player offers one of the most sonically advantages avenues for audio playback created in the last decade, with pristine data transmission over long distances, without loss of signal or degradation from cable runs. This means your server can be located anywhere on the network rather than in your listening space, creating a clutter-free listening environment and ground-breaking performance.
Masterfully connected
The M11S2 digital input selection is well appointed to fit most any system. It also features a fully differential design which creates a less resistant output signal path, ideal when matched with fully differential M20 preamplifier and the Bricasti M28 and M25 amplifiers.
About Bricasti Design
Bricasti Design is a premier manufacturer in the professional audio industry, renowned for its meticulous craftsmanship and high-performance products. With a legacy rooted in the design of the legendary Lexicon reverb units, Bricasti Design has continued to innovate, setting new standards in both analog and digital audio solutions. At the heart of Bricasti's product lineup is the acclaimed Bricasti M7 digital reverb, a staple in recording studios worldwide. Known for its unparalleled sound quality and versatile presets, the Bricasti Design M7 (model 7) delivers lush, natural reverb that enhances any audio production. The M7's front panel features intuitive controls and a sleek design, ensuring ease of use for professionals.
In addition to unique reverb units and plugins, Bricasti Design offers a range of top-tier audio products, including amplifiers (amps), preamps, DACs, and DSP modules. Their analog and digital amplifiers are engineered to provide precise and powerful sound reproduction, making them ideal for both studio and live applications. The company's preamps and compressors are designed with the same attention to detail, ensuring that every aspect of the audio signal chain is optimized for high-resolution performance.
Bricasti's M-series digital to analog converters, such as the Bricasti M1, are celebrated for their exceptional clocking and pristine audio quality, making them a favorite among audiophiles and recording engineers alike. These DACs offer high-end algorithms and comprehensive connectivity options, including AES, XLR, SPDIF, and MIDI, ensuring seamless integration with any digital audio workstation (DAW) setup. Handcrafted to perfection in the USA, Bricasti's products are built with robust outboard modules and reliable power supplies, guaranteeing durability and long-term performance. The company also offers remote control capabilities for many of its devices, allowing for convenient operation in complex studio environments.
For live sound and touring, Bricasti's range of pedals, mics, and other pro audio gear provide the reliability and quality that professionals demand. Each product is backed by a solid warranty, reflecting Bricasti's commitment to excellence and customer satisfaction. Bricasti Design continues to push the boundaries of professional audio, offering innovative solutions that cater to the needs of today's recording studios, sound engineers, and musicians. Whether you're looking for the perfect stereo reverb processor, a high-fidelity DAC, mainframe, or robust analog amplification, Bricasti Design delivers exceptional performance and unmatched quality.
Features
- Dual-mono design with isolated left and right channels for exceptional stereo separation
- Premium 20-bit ladder-type D/A conversion for natural, transparent sound reproduction
- Advanced MDx digital processor with proprietary filter technology
- Ultra-low jitter (8 psec @ 48kHz) using Direct Digital Synthesis (DDS) clocking
- Multiple digital inputs including AES/EBU, SPDIF, Toslink, USB, and optional network player
- Full DSD support up to DSD256 via USB (DSD64/128 via other inputs)
- Selectable digital filters for personalized listening experience
- Balanced (XLR) and unbalanced (RCA) analog outputs
- Handcrafted in USA with precision-machined aluminum chassis
What's in the Box?
- Bricasti M11 Series II R2R D/A Converter
- Power cord
- User manual
- Remote Control
- Warranty card (2-year parts and labor warranty)
FAQ
What makes the Bricasti M11 Series II different from other Bricasti DACs?
The M11 Series II stands out with its fully differential R2R ladder DAC architecture, offering a distinctively smooth and natural analog sound. Unlike other Bricasti models that use delta-sigma conversion, the M11 focuses on precision resistor-based conversion and dual-mono design for unmatched musicality, transparency, and harmonic depth. It also integrates a network media renderer (NMR) for direct streaming, making it a powerful all-in-one digital front end.
What is the core design philosophy behind the M11 Series II?
The M11 Series II is designed with purist audiophiles in mind. Its R2R ladder DAC topology delivers a non-oversampling, non-filtered signal path for pure, unaltered sound. The design eliminates unnecessary digital processing to preserve the integrity of the original recording, paired with Bricasti’s handcrafted chassis and dual linear power supplies for the lowest noise floor possible.
What connectivity options are available on the M11 Series II DAC?
The M11 Series II is equipped with a wide range of digital inputs, including USB, AES/EBU, coaxial, optical, and Ethernet. It also features balanced XLR and unbalanced RCA analog outputs. The inclusion of a built-in network renderer (supporting Roon, DLNA, and other streaming protocols) allows it to function as both a DAC and a high-end streaming device.
Does the Bricasti M11 Series II support high-resolution and DSD playback?
Yes, the M11 Series II supports high-resolution PCM and native DSD playback through USB and network inputs. Its advanced design ensures accurate reproduction of high-resolution audio files, making it ideal for both DSD and PCM libraries.
How does the M11 Series II perform in terms of sound quality?
Thanks to its R2R DAC design, the M11 Series II delivers an exceptionally natural and analog-like sound. Listeners often describe its performance as detailed yet musical, with rich tonality, deep soundstage, and superb imaging. It excels in revealing the subtle textures of recordings while maintaining emotional engagement and realism.
| Category | Specification |
|---|---|
| Digital Inputs | XLR (AES/EBU 24-bit Single Wire), BNC (SPDIF), RCA (SPDIF), Optical (Toslink 44.1–96kHz), USB 2.0 |
| Sample Rates (AES, SPDIF, AUX) | 44.1kHz to 192kHz |
| Sample Rates (USB) | 44.1kHz to 384kHz, DSD 64 / 128 / 256 (Native or DoP) |
| Sample Rates (Ethernet - optional) | 44.1kHz to 384kHz PCM, DSD 64x / 128x (Native and DoP) |
| Jitter | 8 psec @ 48kHz / 6 psec @ 96kHz |
| Balanced Analog Outputs | XLR (Pin 2 hot) |
| Balanced Output Impedance | 40 ohms |
| Balanced Output Level | Internally selectable: +13.5 dBm or +10 dBm |
| Unbalanced Analog Outputs | RCA |
| Unbalanced Output Impedance | 40 ohms |
| Unbalanced Output Level | +8 dBm (2V RMS) |
| D/A Conversion | 20-bit Ladder Type |
| Frequency Response @ 44.1kHz | 10Hz – 20kHz, +0dB / -0.2dB |
| Dynamic Range | >120dB A-Weighted |
| THD+N @ 1kHz | 0.0020% @ 0dBfs |
| EMC Compliance | EN 55103-1, EN 55103-2, FCC part 15 Class B |
| RoHS Compliance | EU RoHS Directive 2002/95/EC |
| Safety Certification | IEC 60065, EN 55103-2 |
| Operating Temperature | 32°F to 105°F (0°C to 40°C) |
| Storage Temperature | -22°F to 167°F (-30°C to 70°C) |
| Finish | Anodized aluminum, nickel plating with brass knobs and buttons |
| Dimensions | 17" x 12" x 4.5" |
| Weight | 15 lbs |
| Shipping Weight | 18 lbs |
| Shipping Dimensions | 22" x 17" x 7" |
| Mains Voltage | 100, 120, 220, 240 VAC, 50–60Hz (factory set) |
| Trigger Out | TRS mini jack (Tip: ground, Sleeve: 5V) |
| Power Consumption | 28W (6W standby) |
| Warranty | 2 years, parts and labor (non-transferable) |
