Matrix Audio
MP-1 Preamplifier
$6,999.00 USDPay Over Time
Split your purchase into easy payments.
Fast approval with Klarna.
Select Klarna at checkout to split your purchase into smaller payments.
Features
Fully differential transistor input stage circuit design
The main amplifier consists of four independent fully balanced amplification units. Each channel has two amplification units working together
Features 3 pairs of RCA and 3 pairs of XLR inputs, with the ability to independently set level attenuation and compensation for each input
Features 1 pair of RCA outputs and 2 pairs of XLR outputs, capable of output simultaneously or separately
Voltage-divider volume control
Two customized high-power square copper wire toroidal transformers
What's in the Box?
Warranty
The Matrix Audio MP-1 Preamplifier is a state-of-the-art preamp designed for audiophiles who demand unparalleled audio performance. At the heart of the MP-1 lies a high-bias current single triode pure Class-A output, ensuring a rich, warm sound signature. The fully differential transistor input stage circuit design and the main amplifier, consisting of four independent fully balanced amplification units, provide impeccable signal integrity and exceptional sonic clarity. Each channel utilizes two amplification units working in tandem for superior audio reproduction.
The MP-1 offers versatile connectivity with 3 pairs of RCA and 3 pairs of XLR inputs, allowing users to independently set level attenuation and compensation for each input. Outputs include 1 pair of RCA and 2 pairs of XLR, which can operate simultaneously or separately, providing flexibility in your audio setup. The voltage-divider volume control ensures precise and smooth volume adjustments, maintaining the integrity of the audio signal.
Powering the MP-1 are two customized high-power square copper wire toroidal transformers, delivering consistent and clean power to the unit. The MP-1 Preamplifier combines advanced engineering with elegant design, making it an essential component for any high-fidelity audio system. Experience the ultimate in audio purity and performance with the Matrix Audio MP-1 Preamplifier.
Dragon Cable Recommendation: We recommend pairing the Matrix Audio MP-1 Preamplifier with our popular Silver Dragon Interconnect. Sold in Pairs, the Silver Dragon V2 is our top-of-the-line silver conductor-based interconnect. With a braided geometry and amazing shielding, this interconnect is a remarkable solution where noise isolation is key. We also recommend using the Black Dragon Power Cable, designed to be used with all equipment in mind: DVD/CD Players, Dacs, Home Theater Processor/Pre Amps, and speaker/headphone amps. The cable is dead quiet and rejects all EMI and RFI interference.
Features:
- High bias current single triode pure Class-A output
- Fully differential transistor input stage circuit design
- The main amplifier consists of four independent fully balanced amplification units. Each channel has two amplification units working together
- Features 3 pairs of RCA and 3 pairs of XLR inputs, with the ability to independently set level attenuation and compensation for each input
- Features 1 pair of RCA outputs and 2 pairs of XLR outputs, capable of output simultaneously or separately
- Voltage-divider volume control
- Two customized high-power square copper wire toroidal transformers
A New Generation of HiFi Excellence
The all-new M series marks a significant milestone for Matrix Audio as it advances towards traditional Hi-Fi systems. This series includes the MS-1 music streamer, MP-1 preamplifier, and MA-1 power amplifier, creating a complete flagship system that embodies Matrix Audio's understanding of Hi-Fi audio. The M series is the first lineup to feature the new Matrix Design language, setting the stage for the future evolution of Matrix Audio products.
Evaluating audio products through the lenses of "listening" and "looking" has always been central to Matrix Audio's philosophy. From concept to design, every step reflects a passion for music and a pursuit of beauty. The MP-1, Matrix Audio's first Class A preamplifier, exemplifies this ethos. Its industrial design emphasizes simplicity, featuring an array of hundreds of circular perforations of varying sizes and depths on a simple hexahedron, evoking the rhythm of dancing beats.
A Warm and Mellow Audio System
The preamplifier serves as the commander of the audio system, delivering precise instructions to optimize the performance of the audio source and power amplifier. The MP-1 is a crucial link in this chain, processing input music with accuracy and infusing it with rich tones and textures. It enables you to hear the nuances, see the intricacies, and feel the soul of the music. Essentially, it is the sculptor of your auditory experience.
The fully differential transistor input stage circuit design ensures extremely low noise and excellent linearity. The output stage features a high-bias current pure Class A output, eliminating crossover distortion. Operating under a low-noise power supply of up to 60V, it achieves an extraordinary dynamic range. The output DC servo circuit maintains the output midpoint offset within 1mV, avoiding coupling capacitors to ensure a flatter frequency response, preserving the original sound in its purest form.
Four Independent Amp Units
Multiple Analog Inputs
The main amplifier of the MP-1 comprises four independent, fully balanced amplification units. Each channel features two amplification units working in tandem, amplifying both the in-phase and inverted signals. Even in RCA input mode, the signal is converted into a bipolar signal for amplification, effectively suppressing common-mode noise and enhancing dynamic performance.
The MP-1 features 3 pairs of RCA inputs and 3 pairs of XLR inputs, each with independently adjustable level attenuation and compensation. This design ensures consistent amplitude across all input signals, eliminating volume differences when switching between different audio sources.
Great I/O for Flexible Applications
Precision In Detail
The MP-1 offers 1 pair of RCA outputs and 2 pairs of XLR outputs, which can function simultaneously or separately. When used separately, each output’s volume can be individually adjusted, allowing for comfortable volume levels when connecting multiple power amplifiers and various speakers. When both XLR outputs are utilized concurrently, up to four power amplifiers can be connected to drive the mid-high and low-range drivers of the speakers separately, enabling a bi-amping mode.
The MP-1 utilizes a voltage-divider volume control system made from a resistor array. It incorporates four high-quality volume control units, each comprising 64 precision resistors with 0.001 accuracy and 32 fully sealed reed relays, rapidly switched by the MCU. This method minimizes any impact on sound quality and ensures excellent consistency between the two channels. Additionally, the operation noise of the reed relays is almost inaudible, even during continuous volume adjustments.
Square Copper Wire Transformer and Linear Power
Power is the foundation of any audio device, and even a preamplifier needs sufficient power reserves. The MP-1 is equipped with two 60W high-power square copper wire toroidal transformers, which independently power the volume control units of the left and right channels as well as the main amplification unit. This design achieves true independent dual-channel operation from the source. Square copper wire, compared to traditional toroidal transformers with circular cross-section wire, offers a larger conductor surface, higher current capacity, and lower resistance, resulting in better transient response and richer low frequencies. Paired with MUNDORF's M-Lytic AG series filter capacitors, it delivers a silky smooth and mellow sound.
H-Shaped Chassis Structure
The H-shaped structure is a distinctive design developed by Matrix Audio for the M series products, resulting from two years of continuous optimization and refinement across mechanics, circuit layout, and exterior appearance. A 20mm CNC aluminum plate serves as the support structure for the entire device after undergoing numerous procedures, acting as the core of the H-shaped structure. All components are mounted on this aluminum plate, with the entire weight supported by heavy-duty feet attached to the main beam, ensuring solidity and stability. Once the panels are installed, the main beam creates multiple isolated cavities. Different circuit modules are precisely placed within these cavities, effectively reducing interference between them. The circuit modules for the left and right channels are symmetrically arranged on both sides, providing a balanced visual impression.
Crafted with precision and artistry, our product embodies the essence of the Matrix Design language, derived from meticulous attention to detail in every aspect of its construction. Each component undergoes intricate CNC machining and surface treatments, resulting in an exquisite matte texture that exudes elegance and sophistication. The seamless integration of dots, lines, and surfaces reflects our commitment to unparalleled craftsmanship, ensuring a unique and refined user experience that captivates the senses.
Warm and Delicate Sound
The MP-1 preamplifier envelops listeners in a warm, nuanced sound, blending powerful lows with crisp highs for an immersive listening experience across genres. From chamber music to symphony orchestras, the MP-1 delivers flawless audio reproduction, reflecting our commitment to excellence. Every element of the M series epitomizes our dedication to perfection, meticulously crafted through relentless refinement and precise calibration. With each note, sight, and touch, Matrix Audio presents a culmination of our unwavering pursuit of beauty and captivating sound.
About Matrix Audio:
Matrix Audio is a cutting-edge company specializing in high-quality digital audio products. Known for its innovative DACs and audio interfaces, Matrix Audio caters to audiophiles and professionals alike. The Mini-i Pro 4/Mini-i 4 and X-Sabre 3 converters support advanced formats like DSD and MQA, ensuring pristine audio reproduction. The Element Series, including the Element S music streamer and the Matrix Audio Element all-in-one headphone amplifier units (Element i2, Element X2 Pure, etc.), feature ESS DACs, digital inputs, Ethernet connectivity, and wi-fi capabilities for seamless integration. With features like PCM playback, analog outputs, and touch screen interfaces, Matrix Audio products provide exceptional versatility. The Pro and headphone amp models, such as the Matrix X-Sabre, offer powerful amplification and refined sound quality. Additionally, Matrix Audio products are Roon Ready and support Airplay, Qobuz, Spotify Connect, and Tidal Connect, providing a superior streaming experience. The latest units support a wide array of I/O from IIS-LVDS, coaxial, spdif, USB input, AES, and more. The convenience of remote control and modern design make Matrix Audio a leading choice for digital and analog audio enthusiasts.
What's in the Box?
- Matrix Audio MP-1
- RM4C remote control
- Power cable
- Trigger cable
- User manual
- Warranty card
FAQ
What are the key features of the Matrix Audio MP-1 Preamplifier?
The MP-1 boasts a high-bias current single triode pure Class-A output, a fully differential transistor input stage circuit design, and four independent fully balanced amplification units, among other advanced features.
How does the MP-1 handle input and output connections?
It offers 3 pairs of RCA and 3 pairs of XLR inputs, with individual-level attenuation and compensation settings for each input. It also includes 1 pair of RCA outputs and 2 pairs of XLR outputs, which can be used simultaneously or separately.
Can you adjust the volume levels precisely on the MP-1?
Yes, it features a voltage-divider volume control with high-quality components and precision resistors, ensuring accurate and consistent volume adjustment with minimal impact on sound quality.
What kind of power supply does the MP-1 use?
It is equipped with two customized high-power square copper wire toroidal transformers, providing independent power to the volume control unit and the main amplification unit, resulting in enhanced transient response and low-frequency performance.
How does the MP-1 contribute to overall audio quality in a system?
With its sophisticated circuitry design and meticulous construction, the MP-1 delivers warm, detailed sound reproduction, maintaining clarity and power across the frequency spectrum.
Does the MP-1 integrate seamlessly with other Matrix Audio components?
Yes, it is designed to complement other Matrix Audio products, forming part of a cohesive audio system with uncompromising performance and compatibility.
What is the build quality like on the MP-1?
The MP-1 features a robust construction with meticulous CNC machining and surface treatments, showcasing Matrix Audio's commitment to craftsmanship and durability.
How does the MP-1 compare to other preamplifiers on the market?
The MP-1 stands out for its innovative design, advanced features, and exceptional audio performance, making it a top choice for discerning audiophiles seeking premium-quality sound reproduction.
Specifications
- XLR input Impedance
- 40kΩ
- RCA input Impedance
- 20kΩ
- XLR Output Impedance
- 40Ω
- RCA Output Impedance
- 20Ω
- Maximum XLR Input Level
- 9Vrms
- Maximum XLR Output Level
- 36Vrms
- Maximum RCA Input Level
- 4.5Vrms
- Maximum RCA Output Level
- 18Vrms
- Frequency Response
- 20-20kHz ±0.1 250kHz@-3dB
- Dynamic Range of XLR Output
- 129dB@A-weighting, 125dB@Unweighting
- Dynamic Range of RCA Output
- 125dB@A-weighting, 120dB@Unweighting
- THD+N of XLR Output
- <0.00015%@A-weighting, <0.00020%@Unweighting
- THD+N of RCA Output
- <0.00040%@A-weighting, <0.00040%@Unweighting
- Crosstalk of XLR Output
- -140dB
- Crosstalk of RCA Output
- -130dB
- Gain
- +12dB
- Volume Steps
- 100
- Trigger in
- DC 6-12V < 10mA
- Trigger out
- DC 12V/50mA MAX
- Power Voltage
- AC 100V-120V 50/60Hz or AC 220V-240V 50/60Hz Factory fixed
- Standby Power Consumption
- < 1W
- Maximum Power Consumption
- < 70W
- Weight
- 15.7kg (34.6 pounds)
- Size
- Width: 430 mm (16.93 inches)
- Depth: 349 mm (13.74 inches)
- Height: 106 mm (4.17 inches)
