Matrix Audio
MA-1 Power Amplifier
$7,999.00 USDFeatures
Total capacity of filter capacitor array reaches 190,000µF
Output power: 250Wrms*2@8ohms, 450Wrms*2@4ohms
Ten ONSEMI high-power transistors in each channel to compose a push-pull amplification circuitry
Output gain is configurable, the normal gain is +30dB, which can be attenuated to +24dB by the gain switch
Independent transformer for left and right channel
The MCU continuously samples the temperature with two sensors on the main heatsink, constantly monitoring the temperature of the heatsink.
What's in the Box?
Warranty
The all-new M series from Matrix Audio marks a significant milestone as the company advances its vision towards traditional high-fidelity audio systems. This flagship lineup includes the music streamer MS-1, the preamplifier MP-1, and the crown jewel – the MA-1 power amplifier. Together, these components form a complete and cohesive system that represents Matrix Audio's unwavering pursuit of sonic excellence and its profound understanding of the art of hi-fi audio reproduction.
At the heart of this prestigious system lies the MA-1 power amplifier, a masterpiece of engineering that embodies Matrix Audio's commitment to pushing the boundaries of performance and innovation. The MA-1 features a multi-triode in parallel push-pull output configuration, ensuring a powerful and dynamic sound delivery while preserving the natural warmth and intimacy of the music.
One of the standout features of the MA-1 is its exceptional versatility. It can operate in stereo mode, bridged mode, or mono mode, providing audiophiles with the flexibility to tailor the amplifier's performance to their specific system requirements. Furthermore, the adjustable gain functionality allows for seamless integration with a wide range of preamplifiers and sources.
At the core of the MA-1's design lies an independent dual-channel architecture, each channel boasting its own robust 1250VA power supply. This massive power reserve ensures that the amplifier can effortlessly handle even the most demanding transients and dynamic swings, delivering an uncompromised and captivating listening experience.
The MA-1 also showcases Matrix Audio's attention to detail and commitment to excellence in every aspect of its design. Its H-shaped structure provides a solid and sturdy foundation, while the silent cooling system ensures whisper-quiet operation, allowing you to immerse yourself in the music without distractions. With its cutting-edge technologies, exceptional versatility, and unwavering commitment to sonic purity, the Matrix Audio MA-1 power amplifier stands as a testament to the brand's pursuit of audio perfection. As the centerpiece of the M series, it ushers in a new era of Matrix Design language, serving as a precursor to the future evolution of Matrix Audio products and elevating the listening experience to new heights.
Dragon Cable Recommendation: We recommend pairing the Matrix Audio MA-1 power amplifier with the popular Silver Dragon Interconnect. Sold in Pairs, the Silver Dragon V2 is our top-of-the-line silver conductor-based interconnect. With a braided geometry and amazing shielding, this interconnect is a remarkable solution where noise isolation is key. The Black Dragon Power Cable is also recommended to provide the cleanest and unbridled power supply to your high-end amplifier.
Features:
- Total power supply reaches 1250VA
- Total capacity of filter capacitor array reaches 190,000µF
- Output power: 250Wrms*2@8ohms, 450Wrms*2@4ohms
- Ten ONSEMI high-power transistors in each channel to compose a push-pull amplification circuitry
- Output gain is configurable, the normal gain is +30dB, which can be attenuated to +24dB by the gain switch
- Independent transformer for left and right channel
- The MCU continuously samples the temperature with two sensors on the main heatsink, constantly monitoring the temperature of the heatsink.
Matrix Design for a New Generation of Power Amplifier
Assessing audio products through the lens of "listening" and "looking" has always been Matrix Audio's consistent philosophy. From conception to design, each step embodies a passion for music and a quest for aesthetics. The MA-1 stands as Matrix Audio's inaugural Class AB power amplifier. Its industrial design embodies simplicity, featuring a hexahedral shape adorned with hundreds of circular perforations of varying sizes and depths arranged in an array. These resemble rhythmic beats dancing and emerging on the surface.
The power amplifier stands as the backbone of the entire audio system, necessitating comprehensive performance that excels in both dynamic and nuanced scenarios. It should surge powerfully during intense moments and delicately reveal subtleties with finesse. The MA-1 is tailored for the MS-1 and MP-1, providing precise matching and tuning to ensure that the entire system delivers exceptional audio performance and operational experience.
Multi-triode In Parallel Push-pull Output
To reduce output impedance, we utilized 10 ONSEMI high-power transistors per channel in a push-pull amplification circuit, operating at a high bias current. This design results in a static power consumption of up to 300W. The amplifier delivers 250W per channel at an 8-ohm load and 450W per channel at a 4-ohm load.
Stereo Mode: Each amplification unit within one amplifier handles the left and right channels separately, ensuring precise reproduction of every note on the stereo stage.
Bridged Mode: By combining two power amplifiers, you can unleash greater power for your music, effortlessly driving speakers with demanding power requirements or low sensitivity.
Mono Mode: Two amplifiers work for each channel, aiming for extreme sound quality. This mode provides an advanced driving setup for high-end separate speakers or bi-wiring speakers, unlocking their full potential.
Adjustable Gain: The amplifier features two gain levels. The normal gain is +30dB, which can be attenuated to +24dB. This allows for optimal setup with different pre-amps and speakers.
Independent transformers for the left and right channels enable a fully independent dual-channel design, providing a total power supply of 1250VA. The main power operates at ±80V. Each channel is equipped with 14 parallel-connected 6,800µF capacitors, forming a main power supply filtering capacitor matrix. This results in a total capacitance of 190,000µF across both channels. Using multiple capacitors in parallel, instead of a single capacitor with the same total capacity, reduces equivalent internal resistance and ensures greater flexibility in handling large current outputs.
A New and Unique Craftsmanship
The H-shaped structure, a distinctive design by Matrix Audio for the M series products, is the result of two years of continuous optimization and refinement, taking into account mechanics, circuit layout, and exterior aesthetics. A 20mm CNC aluminum plate serves as the support structure for the entire device after undergoing dozens of procedures, forming the core of the H-shaped design. All components are mounted on this aluminum plate, with the entire weight supported by heavy-duty feet attached to the main beam, ensuring solidity and stability. Once the panels are installed, multiple isolated cavities are formed around the main beam. Different circuit modules are strategically placed in each cavity, effectively minimizing interference between them. The circuit modules for the left and right channels are symmetrically arranged on both sides, creating a balanced and visually appealing design.
Silent Cooling
The MCU continuously samples the temperature using two sensors on the main heatsink, ensuring constant monitoring. When the temperature exceeds the preset threshold, a 7.4" ultra-quiet fan automatically activates, dynamically adjusting its speed. The fan operates so quietly that it is barely noticeable even at low volumes or when the device is muted. Additionally, the isolated duct design ensures no electronic components are within the airflow path, preventing dust accumulation during long-term operation.
The ingenious industrial design is an integral part of Matrix Audio's products, showcasing the brand-new Matrix design language through dots, lines, and surfaces. Each component undergoes meticulous CNC machining and multiple surface treatments, resulting in an exquisite and comfortable matte texture. This craftsmanship not only enhances the operational experience but also imparts a distinctive and elegant temperament to the product.
The MA-1 delivers rich and exquisite sound, immersing you in its depths. It's more than just an auditory pleasure; it's a heartfelt experience. Every note and chord tells a story, making you fall in love with the sound. Every detail of the M series reflects Matrix Audio's pursuit of excellence. Everything you hear, see, and touch represents the culmination of the Matrix Audio team's continuous trials, meticulous refinements, and careful calibrations. Matrix Audio perseveres tirelessly, striving to enhance beauty and make the sound even more captivating.
What's in the Box
- Power cable x 1
- Trigger cable x 1
- User manual x 1
- Warranty card x 1
FAQ
What makes the Matrix Audio MA-1 power amplifier stand out from other amplifiers?
The Matrix Audio MA-1 stands out due to its unique H-shaped structure, high-power output, independent dual-channel design, advanced thermal management, and meticulous craftsmanship. It offers both stereo and mono operation modes, providing flexibility and exceptional sound quality.
What kind of audio experience can I expect from the MA-1?
The MA-1 delivers a rich and exquisite sound, with deep immersion and a detailed auditory experience. It is designed to provide a balanced, dynamic, and transparent sound that captures every nuance of the music.
What are the power output specifications of the MA-1?
The MA-1 provides 250W per channel at an 8-ohm load and 450W per channel at a 4-ohm load, thanks to its high-power push-pull amplification circuitry and 10 ONSEMI high-power transistors per channel.
How does the impedance matching work on the MA-1?
The MA-1 features an impedance selector switch for the output transformer secondaries, allowing users to match the amplifier's output impedance to the impedance of their headphones, ensuring optimal performance and sound quality.
What is the significance of the H-shaped structure in the MA-1?
The H-shaped structure, unique to Matrix Audio's M series, provides a robust support framework and reduces interference between circuit modules. This design ensures solid stability and optimizes the layout for better sound quality.
How does the MA-1 manage heat dissipation?
The MA-1 uses an MCU that continuously samples temperature with two sensors on the main heatsink. When the temperature exceeds the preset value, a 7.4" ultra-quiet fan automatically runs and adjusts the fan speed dynamically. The isolated duct design prevents dust accumulation, ensuring long-term reliability.
What input options are available on the MA-1?
The MA-1 offers both balanced and single-ended inputs, providing flexibility for connecting various audio sources. The balanced inputs are equipped with Lundahl transformers for optimal signal integrity and noise rejection.
Does the MA-1 support adjustable gain settings?
Yes, the MA-1 has two gain levels. The normal gain is +30dB, which can be attenuated to +24dB, allowing for setup compatibility with different pre-amps and speakers.
How do I properly set up the MA-1 in a stereo or mono configuration?
In stereo mode, each amplification unit handles the left and right channels separately. In bridged mode, two amplifiers are combined for more power. In mono mode, two amplifiers work for each channel, offering advanced driving for high-end speakers.
Specifications
- Audio Specifications
- XLR Input Impedance
- 40kΩ
- RCA Input Impedance
- 20kΩ
- Input Sensitivity
- 1.48Vrms@Stereo/Mono mode, 1Vrms@Bridge mode
- Output Power in Stereo/Mono mode
- 250Wrms*2@8Ω, 450Wrms*2@4Ω
- Output Power in Bridged mode
- 500Wrms*1@8Ω, 900Wrms*1@4Ω (Measured under music signal)
- Frequency Response
- 20-20kHz (+0, -0.15dB), 142kHz@-3dB
- SNR
- -122dB@+24dB A-weighting, -118dB@+30dB A-weighting
- THD+N
- <0.02%@250W 8Ω in Stereo/Mono mode, <0.06%@500W 8Ω in Bridged mode
- Crosstalk
- -120dB
- Gain
- +24dB/+30dB
- Load Impedance
- Stereo/Mono mode 2-16Ω, Bridged mode 4-16Ω
- Trigger
- Trigger in: DC 6-12V <10mA
- Trigger out: DC 12V/50mA MAX
- Power Specs
- Power Voltage: AC 100V-120V 50/60Hz or AC 220V-240V 50/60Hz Factory fixed
- Standby Power Consumption: < 1W
- Idle Power Consumption: 250-350W
- Maximum Power Consumption: < 1250W
- Weight & Size
- Weight: 42.4kg (93.5 pounds)
- Size
- Width: 430 mm (16.93 inches)
- Depth: 518 mm (20.39 inches)
- Height: 201 mm (7.91 inches)
