Wattson Audio
Madison Streamer (previously LE Streamer)
$4,995.00 USDFeatures
Support for PCM and DSD high-definition formats
New up-sampling process with time-domain optimization, a legacy of the famous Anagram Technology up-samplers
64-bit Digital Volume Control to preserve microdynamic nuance and low-level detail with exceptional fidelity
Adjustable bass response to compensate for speaker placement near walls
Ultra-low phase noise oscillators
One D/A converter chip per channel in dual differential mode
Full-symmetric analogue output stages
Very low-noise power supply circuits
CNC-machined out of a solid aluminium block
Design, manufacturing, and assembling entirely made in Switzerland
Video
What's in the Box?
Warranty
Swiss Precision Meets Musical Engagement
The new Madison Streamer represents a streamlined evolution of Wattson Audio’s celebrated network player. With the retirement of the Classic and Lounge Edition models, the Madison line now converges into a single, unified design that preserves the performance and topology of the Madison Lounge Edition, while introducing refined exterior detailing. Internally, it remains identical to its predecessor—built around Wattson Audio’s proprietary streaming platform, renowned for its natural, time-coherent musicality. Externally, the updated cosmetics and simplified model structure bring visual harmony to the Madison family while maintaining the precision, warmth, and expressive musical flow that have made it a benchmark in its category.
Designed with a singular focus on delivering extraordinary sound in its purest form, the Madison Streamer continues the legacy established by the acclaimed Lounge Edition. Its exceptionally low noise floor and robust output stage provide the authority and control needed to drive connected amplifiers with effortless precision. The result is a musical experience alive with dynamic contrast, tonal finesse, and emotional depth—qualities typically reserved for far larger and more costly components. True to Wattson Audio’s engineering philosophy, the Madison Streamer embodies a perfect balance of technical mastery and musical artistry, reaffirming the brand’s commitment to purity, precision, and performance.
Wattson Audio's Pinnacle of Precision and Performance
The Madison Streamer is Wattson Audio’s definitive expression of digital playback and control. Designed and engineered entirely in-house, it combines a robust analog output stage with advanced DSP architecture—the foundation not only for its effortless musical precision and emotional depth, but also for continuous refinement over time. This flexible digital platform allows Wattson to implement meaningful performance upgrades, such as the new high-precision digital volume control, developed to enhance transparency, dynamic nuance, and musical realism. Supporting both network streaming and S/PDIF digital sources, the Madison offers balanced and single-ended outputs for seamless integration with power amplifiers, preamplifiers, or integrated systems. Compact, elegant, and uncompromising in performance, it embodies the essence of a modern high-end digital source—pure, precise, and profoundly musical.
The Madison Streamer reflects Wattson Audio’s belief that great sound is born from balance—between technical precision and musical flow, between simplicity and sophistication. Every subsystem is optimized not in isolation, but as part of a coherent whole, ensuring that digital, analog, and power stages operate in perfect harmony. Its minimalist circuitry is meticulously tuned to minimize signal loss, reduce noise, and preserve dynamic integrity. The result is a product that feels both effortless and exacting—an instrument of musical truth shaped by experience, not excess.
Form, Function, Fidelity
The Madison Streamer represents Wattson Audio’s most complete expression of digital playback and control. Designed and engineered entirely in Switzerland by the same team behind CH Precision, it embodies a philosophy where technology serves musical emotion with effortless grace.
At its core lies a powerful DSP-based DAC architecture that merges advanced digital signal processing with a meticulously executed analog output stage. Supporting both network and S/PDIF digital sources, the Madison delivers balanced and single-ended outputs for seamless integration with any system—whether driving a power amplifier directly or partnering with a preamplifier or integrated design. The result is a sound that combines precision and warmth, structure and soul—a compact yet uncompromising component that reveals music with striking realism and fluidity.
Refining the Volume Control
Developed in collaboration with CH Precision, Wattson’s new digital volume control was created specifically for the Madison platform. Replacing the former LEEDH implementation, it’s a fully in-house design shaped by a balanced process of mathematics, measurement, and critical listening. At its core, a 64-bit digital attenuator preserves even the smallest signal changes with absolute integrity. Operating in 0.5 dB steps verified to within ±0.1 dB, it maintains exceptional accuracy and linearity by minimizing truncation and rounding errors.
Existing Lounge Edition Madison Streamers will receive this new digital volume control via firmware update, ensuring every owner benefits from the same precision, refinement, and performance as the latest model.
Engineered for Musical Realism
At the heart of the Madison’s digital architecture lies the Wattson Spline filter—a proprietary algorithm derived from the same design principles used in our cost-no-object CH Precision siblings. Optimized for time-domain accuracy, it minimizes both pre- and post-ringing, preserving transient integrity and musical flow. While other manufacturers offer multiple selectable filters, Wattson perfected a single, purpose-built implementation—one that faithfully reproduces the timing and texture of real instruments.
The Madison supports PCM playback up to 32-bit/384 kHz and DSD up to 256x (11.2896 MHz) via network streaming, and PCM up to 24-bit/192 kHz through its S/PDIF input. These specifications aren’t about numbers for their own sake—they translate directly into smoother gradients, greater dynamic headroom, and a more lifelike rendering of musical space. Its refined power architecture employs premium-grade capacitors and enhanced supply capacitance to reduce noise and stabilize voltage for superior tonal balance and low-level detail.
Two Finishes, One Madison
For the first time, the Madison Streamer is offered in two distinct finishes: Light Gray and a new Dark Gray. This expanded palette reflects Wattson Audio’s commitment to precision and visual harmony, allowing the Madison to integrate seamlessly into a wider range of interiors. Light Gray recalls the elegance of the former Lounge Edition, while Dark Gray preserves the timeless purity of the original design. Both deliver the same exceptional performance and craftsmanship—now with a choice of aesthetic expression.
Nothing Without Purpose
Delivering extraordinary musical performance in a compact, accessible form demands precision, discipline, and intent. The Madison Streamer embodies this philosophy—every element exists to serve the music, nothing more and nothing less. Its design reflects Wattson Audio’s belief that true engineering excellence lies in focus: selecting only what enhances fidelity, executing every detail with purpose, and eliminating anything that does not. This clarity of vision transforms technology into an instrument of musical truth.
Equally important is Wattson Audio’s commitment to responsibility and longevity in design. The Madison Streamer is crafted from durable, sustainably sourced materials, chosen for their acoustic integrity and minimal environmental impact. Its precision-machined aluminum chassis is built to endure decades of use, both structurally and sonically. Complementing that physical endurance, the firmware platform is fully updatable and developed entirely in-house, allowing new features to be added quickly and efficiently—such as Wattson’s early implementation of Qobuz Connect. This combination of enduring construction and evolving software protects the owner’s investment while minimizing environmental waste—extending Wattson Audio’s philosophy of purity beyond sound, toward sustainability and permanence.
Cutting-Edge Technology
Meets Swiss Precision
Wattson Audio’s commitment to build quality is evident in every detail of the Madison Streamer. Its precision-machined enclosure, milled from solid billet aluminum, reflects a design philosophy where engineering and aesthetics are inseparable. This approach—more demanding and costly than conventional methods—ensures exceptional structural integrity, superior mechanical damping, and optimal electromagnetic shielding. Each unit is built to perform flawlessly over time, embodying the durability, refinement, and quiet confidence that define Wattson Audio craftsmanship.
Seamless and Versatile Digital Connectivity
At the heart of the Madison Streamer is Wattson Audio’s proprietary streaming engine—developed in-house around the Texas Instruments Sitara processor and refined through years of continuous evolution. This custom platform ensures uncompromising signal integrity, outstanding reliability, and seamless support for high-resolution audio, including native PCM and DSD. The result is effortless performance and a fluid, intuitive user experience.
Beyond streaming, the Madison offers a dedicated S/PDIF input section with 75Ω RCA and TOSLink optical connections for legacy digital sources. Its precision clocking architecture employs ultra-low-phase-noise oscillators for the 44.1 kHz and 48 kHz families, each independently filtered to minimize jitter and noise. A high-performance SHARC DSP drives Wattson’s proprietary upsampling and spline-filtering algorithms, optimized for exceptional time-domain accuracy. Dual WM8742 DACs—one per channel—ensure superior separation, spatial coherence, and tonal purity, preserving the integrity and emotional depth of the music.
Features
- Proprietary bit perfect and asynchronous streaming solution
- Support for PCM and DSD high-definition formats
- New up-sampling process with time-domain optimization, legacy of the famous Anagram Technology up-samplers
- 64-bit Digital Volume Control designed to preserve microdynamic nuance and low-level detail
- Adjustable bass response to compensate for speaker placement near walls
- Ultra-low phase noise oscillators
- One D/A converter chip per channel in dual differential mode
- Full-symmetric analogue output stages
- Very low-noise power supply circuits
- CNC-machined out of a solid aluminium block
- Design, manufacturing and assembling entirely made in Switzerland
What's in the Box?
- 1 Madison
- 1 external power supply 5V DC
- 1 power cord
Wattson Audio Madison Streamer Review: Reference-Level Sound, Desktop Form
Read Time: Approx. 14 min.
TL;DR:
- At $4,995, the Madison delivers reference-level sound quality that rivals components costing four times as much, with Swiss engineering and CH Precision pedigree throughout.
- Don't let the compact size fool you—the Madison produces punchy bass, wide/deep soundstage, and infectious musical energy that belies its modest footprint.
- Achieves the difficult balance of being both analytically revealing and emotionally engaging, with exceptional detail retrieval, impressive imaging/separation, and natural tonal balance that never fatigues.
- Supports PCM up to 32-bit/384kHz and DSD256, works seamlessly with Roon, Qobuz, Tidal, Audirvāna, and includes innovative 64-bit volume control design with exceptional linearity
- Swiss-crafted from precision-machined aluminum billet, upgradeable external power supply, updatable firmware, and available in light or dark gray finishes for discerning audiophiles seeking long-term performance.
Compact Swiss Powerhouse Proves Size Isn't Everything In High-End Audio
Wattson Audio's flagship digital streamer and DAC, the Madison Streamer, delivers accuracy and musical fidelity in a compact form factorAt $4,995, the Madison Streamer is a full-featured component with a DAC, headphone amplifier, volume control, and built-in streaming capabilities. Every element in this streamer exists to serve the music, nothing more and nothing less. This is one of the few network streamers on the market designed with the audiophile in mind.
With the retirement of the classic and lounge edition models, the Madison line now converges into a single unified design that preserves the performance and topology of the Madison Lounge Edition, while introducing refined exterior detailing. This is a component that promises pure sound, pure power, and reference-level performance without the astronomical price tag typically associated with components of this caliber.
This Compact DAC/Amp Has Swiss Reference Sound
PROS
- Exceptional sound-to-size ratio
- Swiss engineering at its finest
- Versatile streaming ecosystem and easy-to-use UI
CONS
- No USB Input
- No balanced 4.4mm jack
- No screen may disappoint some
Design
You're probably asking yourself, "Where's the screen?" Well, that's the beauty of the Madison Streamer. It's a low-profile, easy-to-use audio solution that doesn't need a screen. Let's face it: the flashy features, tiny buttons and knobs, and over-the-top UI are great, but they're not always needed. Sometimes, all the extra fluff can be more of a hindrance than a luxury. So while you may look at the Madison Streamer and see a plain chassis, I see a component designed intentionally–one that delivers you exactly what you paid for; no more, no less.
This minimalist approach keeps as many extra bells and whistles out of the picture as possible to make things as pure as possible. At 6.9" x 7.3" x 2.1", the Madison Streamer is smaller than most home audio hi-fi components. It's the perfect desktop unit that rests comfortably on a shelf or sits hidden away in a cabinet. You don't have to play "keep or toss" with your things to make room for the Madison.
As a true Swiss manufacturer, every detail, from design to assembly, takes place in Switzerland. The Madison is crafted from durable, sustainably sourced materials chosen for their acoustic integrity and minimal environmental impact. The precision-milled aluminum chassis is carved from a solid aluminum billet–a process that is more costly than conventional methods, but it reaps incredible benefits: Structural integrity, superior mechanical damping, and optimal electromagnetic shielding. Each unit is built to perform flawlessly over many years of happy listening.
Externally, the Madison Streamer has been updated with two distinct finishes available: light gray and dark gray, allowing you more flexibility to match the streamer to your existing setup and preferences. A separate external power supply not only provides the ability to upgrade it in the future, but also a clear signal path. While you won't find a screen on the face of the Madison Streamer, what you will find is a large digital volume control that enhances transparency, a 6.3mm headphone jack, and four LED indicator lights for power, coaxial input, Toslink input, and network connection. The 1/4" headphone jack is capable of delivering 150mW on 32 ohms, 50mW on 150 ohms, and 10mW on 600 ohms–more than adequate for most audiophile-grade headphones.
The Madison is primarily controlled through the Wattson Music App (Jump to Features for more information), with access to your library, streaming services, and settings. To power on/off the unit, press and hold the volume control knob for roughly three seconds. Short-press it once to enter standby mode, and long press to power off the unit entirely.
The Madison's connectivity options are curated to serve its primary purpose as a network streamer. There is no USB input, so the component must be connected to your network via Wi-Fi or a wired Ethernet connection. If you choose Wi-Fi, there are dedicated Wi-Fi access points available to support that connectivity. A 100Mbit/s Ethernet port on the back panel provides reliable wired network connectivity for those who prefer a stable, hardwired connection.
The Madison supports S/PDIF digital sources with both RCA coaxial and Toslink optical inputs on the back panel, making it easy to pair with a CD player or other digital sources in your system. The analog outputs include one single-ended pair of RCA connectors and one balanced pair of XLR connectors. The RCA output delivers 2.0V RMS at 0dB FS, while the XLR outputs provide 4.0V RMS at 0dB FS, giving you plenty of output voltage to drive most amplifiers with authority.
Sound
After setting up the Madison Streamer at my desk, which entailed plugging the separate power supply into the unit and connecting an Ethernet Cable, I turned it on, enabled it as an audio zone in Roon, and started enjoying my favorite demo tracks. All in all, this setup took less than 10 minutes–quick and painless. I have a standing desk riser placed on top of my large desktop. There's about seven inches of clearance underneath the riser where the Madison sat perfectly nestled out of the way, yet incredibly close for quick volume adjustments.
I spent about an hour listening via Roon on my desktop and then decided to check out the Wattson Music App, which I had downloaded on my iPhone. I'll be honest, I didn't expect much to change between Roon and Wattson's dedicated app, but there was a noticeable difference in sound quality once I started listening with the app...for the better. The sound was richer, more lively, and came in much clearer and closer. I'm not sure how or why, but I'm not complaining.
Once I launched the app, I faced initial frustration because it kept telling me there was no device to connect to. It prompted me to confirm that both the streamer and my phone were on the same network. What do you know, I had made the rookie mistake of using the guest Wi-Fi, which was indeed not the same network the Madison was connected to. I quickly switched to the correct network, reopened the app, and almost instantly, the Madison popped up as an available device to connect.
Once I connected the device, the app prompted me to access my personal library, one of the supported streaming services, or protocols. Qobuz is our go-to here at Moon Audio, so I logged into my account, accessed my favorites, and started listening. Simple and painless.
The Madison Streamer delivers a sound quality that prioritizes neutrality and accuracy above all else. The headphones or speakers paired with a piece of gear can have a significant impact on the overall sonic presentation. If the headphones are naturally bass-heavy, the entire system can skew that way, making it difficult to decipher which sonic qualities originate from the headphones and which come from the component. Over the years of testing audio gear, I've developed a systematic approach: Begin listening with a neutral-sounding headphone to establish a baseline of the gear's tonality. Once identified, I introduce headphones with more pronounced colorations.
To achieve that neutrality, I started with the Meze Audio 105 AER Headphones, a balanced and naturally organic-sounding pair of cans. From the first few songs, it quickly became clear to me that the Madison is engineered to provide an authentic listening experience, where vocals are rich with emotional depth, instruments are layered with impressive separation and imaging, and details emerge naturally.
The bass response has been a topic of discussion among reviewers, and it deserves a special mention. For a component of this size, the Madison delivers a punchy low-end that's impressive and unexpected. The infamous phrase "Never judge a book by its cover" is what makes the Madison the ultimate underdog. You initially look at this component and think, "How good can the sound quality really be from a unit this small?" Well...pretty dang good. The bass response is perfect. It's not overly bloated and doesn't rumble, but when paired with bassy headphones, it delivers a big, bold mid-bass presentation.
The soundstage is equally impressive, stretching both wide and deep for an awesome three-dimensional space. The most important takeaway from my listening sessions, though, is the Madison's ability to deliver infectious energy and emotion that draws you into the music. There's a lively quality to the sound that keeps you engaged–details are presented with clarity and refinement, but never in a way that feels analytical. The Madison Streamer manages to be both detailed and musical, a combination that's harder to achieve than it might seem.
Whether it's the rhythmic flow of reggae that draws you in, or the nuance and detail of jazz, classical, and complex passages, the Madison conveys your favorite songs with authenticity and emotion. The type of finesse that reveals music exactly as it was meant to be heard.
Tangerine
By Glass Animals
(Dreamland)
365 featuring shygirl bb trickz
By Chari XCX
(Brat and it's completely different but also still brat)
Creatures in Heaven
By Glass Animals
(I Love You So F***ing Much)
NUEVAYoL
By Bad Bunny
(DeBÍ TiRAR MáS FOToS)
Features
- Proprietary bit perfect and asynchronous streaming solution
- Support for PCM and DSD high-definition formats
- New up-sampling process with time-domain optimization, legacy of the famous Anagram Technology up-samplers
- 64-bit volume control architecture minimizes truncation and rounding errors
- Adjustable bass response to compensate for speaker placement near walls
- Ultra-low phase noise oscillators
- One D/A converter chip per channel in dual differential mode
- Full-symmetric analogue output stages
- Very low-noise power supply circuits
- CNC-machined out of a solid aluminium block
- Design, manufacturing and assembling entirely made in Switzerland
The Madison Streamer's technical excellence is attributed to CH Precision, the renowned Swiss high-end audio manufacturer and parent company of Wattson Audio. Internally, the Madison remains identical to its predecessor, the acclaimed Lounge Edition, preserving the topology and circuitry that made that model so successful.
The Madison is built around Wattson Audio's proprietary streaming platform, renowned for its natural, accurate musicality. With a fully balanced differential design using two pairs of op-amps per channel, an exceptionally low noise floor, and a robust output stage, the Madison has the authority needed to drive connected amplifiers with precision. Ultra-low-noise voltage regulators are used to provide optimal power to every critical circuit section in the Madison, from clock generators to synchronization circuits and the analog stage. Upgraded critical capacitors between the DAC chips and the analog output stage have been placed to improve transparency.
The Madison supports PCM playback up to 32-bit/384kHz and DSD up to DSD256 via network streaming, and PCM up to 24-bit/192kHz through its S/PDIF inputs. The internal headphone amplifier is capable of delivering 150mW on 32 ohms, 50mW on 150 ohms, and 10mW on 600 ohms–more than adequate for most audiophile-grade headphones.
DAC Architecture
At the heart of the Madison Streamer sits a powerful DSP-based DAC that merges advanced digital signal processing with a meticulously executed analog output stage. Built around the highly capable Sitara Processor from Texas Instruments and an upgradable DSP-driven DAC, the Madison elevates fidelity and musicality for an emotional listening experience.
64-Bit Volume Architecture
Wattson Audio Madison Streamers use the company's latest digital volume control, which replaces the former LEEDH algorithm, and replaces it with a 64-bit digital attenuator.
This design preserves microdynamic nuance and low-level detail with exceptional fidelity. Operating in precise 0.5dB steps–each verified to within ±0.1 dB–the volume control minimizes truncation and rounding errors, ensuring linearity and accuracy across the full operating range. The result is a volume control that maintains musical integrity whether used as a digital preamplifier or feeding a traditional analog stage.
Music Sources and Streaming Integration
The Wattson Music app provides comprehensive access to multiple music sources. Once the Madison is detected and the connection is established, navigate through the following music sources: Tidal or Qobuz, radio stations offered by Airable, or your local UPnP/DLNA media servers. You'll have access to the full catalog and personal favorites on your Tidal and/or Qobuz account, making it easy to dive into curated playlists, discover new music, or search for the perfect track.
The Madison Streamer is Roon Ready, granting you access to the plethora of features Roon's software provides. The streamer is also designed to work with Audirvāna, a platform capable of playing high-resolution music files on Mac and Windows. With integrated support for streaming services like Qobuz, TIDAL, and HRA, the Madison Streamer integrates seamlessly with Audirvāna's proprietary playback engine.
The Wattson Music app will automatically select the highest streaming quality supported by your subscription, with the option to adjust this setting through the menu beside the service name. With Wattson Music's Queue feature, you can plan an entire listening session, adding full albums, playlists, or individual tracks from your streaming service or media server.
Dragon Cables
[Silver Dragon Coax Digital Cable, Silver Dragon Premium Interconnect Cable, Silver Dragon Network Cable]
To unlock the Madison's extraordinary capabilities, we recommend pairing it with premium cables that match its transparent nature. Moon Audio's Silver Dragon Premium Interconnect Cable, Silver Dragon Coax Digital Cable, and Silver Dragon Network Cable serve as ideal companions, preserving signal integrity while allowing the streamer's exceptional detail and tonal accuracy to shine through. The Silver Dragon interconnects, and Coax Digital Cables maintain the Madison's pristine signal path with superior conductivity and a low noise floor, while the Silver Dragon Network Cable ensures clean, stable network delivery—critical for maximizing the performance of the Madison's sophisticated internal circuitry.
Verdict
At $4,995, the Wattson Audio Madison Streamer delivers reference-level sound quality in a compact form factor that rivals components costing significantly more. The beauty of the Madison lies in its refreshing simplicity and Swiss precision. By focusing exclusively on what truly matters—exceptional digital-to-analog conversion, pristine signal processing, and uncompromising audio performance—Wattson Audio has created a high-end component that embodies a perfect balance of technical mastery and musical artistry.
Don't let the Madison's size fool you–this is the ultimate underdog in the streaming world. The Madison delivers a punchy, impressive bass response with an infectious energy that draws you into the music, revealing exactly what the artist intended. It manages to be both detailed and musical, a combination that's harder to achieve than it might seem. It's a component that proves the old adage "never judge a book by its cover."
The Swiss-engineered chassis, upgradeable power supply, and CH Precision pedigree ensure this is an investment built to last. Unlock the streamer's full potential with our Dragon Audio Cables. Given the Madison's transparent and revealing nature, the Silver Dragon Premium Interconnect Cable, Silver Dragon Coax Digital Cable, and Silver Dragon Network Cable preserve signal integrity and ensure clean delivery without adding unwanted coloration.
Whether you're rediscovering familiar recordings or exploring new music, the Madison Streamer's pure sound reproduction reveals something new with every listen. For discerning audiophiles seeking an uncompromising digital audio source that prioritizes purity, precision, and performance, choose none other than the Wattson Audio Madison Streamer.
Featured Products
Related Videos
These Swiss Amps & Streamers Deserve Every Audiophiles Attention
Stop Buying Amps Wrong! Saros Europa Differential Tube Headphone Amp Review
DACs vs. Amps: What's the Difference & Why You Need Both
What's in the Box
- Wattson Audio Madison Streamer
- 1 External Power Supply 5V DC
- 1 Power Cord
Specifications
Network Streaming Resolution: PCM up to 32-bit 384kHz, DSD up to 256x (11,2896MHz)
S/PDIF Input Resolution: PCM up to 24-bit 192kHz
RCA Output Level (0dB FS): 2.0V RMS
XLR Output Level (0dB FS): 4.0V RMS
Signal-to-noise, weighted (SNR-A): <120dB
Harmonic Distortion (THD+N, 0dB FS): <0.001%
Headphone Output: 2x 150mW on 32 ohms, 2x 50mW on 150 ohms, 2x 10mW on 600 ohms
Supported Standards: UPnP/DLNA, AirPlay, TIDAL Connect, Qobuz Connect, Roon Ready, plays with Audirvana
Streaming Services brought by the Wattson Music iOS App: TIDAL, Qobuz, airable radios, DLNA servers
Supported Audio File Formats: WAV, FLAC, AIFF, ALAC, MP3, AAC, Ogg Vorbis, WMA
Network Input: 100Mbit/s Ethernet
Digital Inputs: 1x S/PDIF on RCA connector, PCM and 1x S/PDIF on TOSLink
Analog Outputs: 1x unbalanced on RCA connectors and 1x balanced on XLR
Headphone Output: 6.35mm jack connector
Dimensions (W x D x H): 174 x 185 x 52mm (6.9 x 7.3 x 2.1 in)
Weight: 1075g (2.37 lbs)
Power Supply: 5V DC, external, medical grade
Power Consumption: 50mW (idle), 3.5W (playing)
| Parameter | Specification |
|---|---|
| Physical Specifications | |
| Dimensions (W × D × H) | 6.9 × 7.3 × 2.1 in (174 × 185 × 52mm) |
| Weight | 2.37 lbs (1075g) |
| Power Specifications | |
| Power Supply | 5V DC, external, medical grade |
| Power Consumption | 50mW (idle), 3.5W (playing) |
| Connectivity Specifications | |
| Network Input | 100Mbit/s Ethernet |
| Digital Inputs | 1× S/PDIF on RCA connector (PCM) 1× S/PDIF on TOSLink |
| Analog Outputs | 1× unbalanced on RCA connectors 1× balanced on XLR |
| Headphone Output | 6.35mm Jack connector |
| Audio Specifications | |
| RCA Output Level (0dB FS) | 2.0V RMS |
| XLR Output Level (0dB FS) | 4.0V RMS |
| Signal-to-Noise Ratio, Weighted (SNR-A) | > 120dB |
| Harmonic Distortion (THD+N, 0dB FS) | < 0.001% |
| Headphone Amplifier Specifications | |
| Headphone Output Power | 2× 150mW on 32Ω 2× 50mW on 150Ω 2× 10mW on 600Ω |
| Digital Audio Specifications | |
| Network Streaming Resolution | PCM up to 32-bit 384kHz DSD up to 256× (11.2896MHz) |
| S/PDIF Input Resolution | PCM up to 24-bit 192kHz |
